Stuv 16-in, Z & Combo

The Stûv 16-in Z Combo is a versatile wood stove that offers exceptional heating performance and a range of installation options. This stove features the classic and elegant design of the Stûv 16, combined with a built-in heat accumulator that can store and release heat over time, providing a steady and even heat output throughout the day. The Stûv 16-in Z Combo is designed to be installed as a freestanding unit or integrated into an existing fireplace, providing flexibility and versatility in its placement. The stove is equipped with a rotating door that allows for a 360-degree view of the fire and precise temperature control.

Description

SPECIFICATIONS

16-in (insert)

Model	16-58 in	16-68 in	16-78 in
EPA power	27 015 BTU\h	24 818 BTU\h	28 765 BTU\h
Maximum power	65 000 BTU\h	82 000 BTU\h	86 000 BTU\h
Nominal heat output	46 000 BTU\h	50 000 BTU\h	58 000 BTU\h
Efficiency	70.3%	61.6%	66.6%
Fine particle emissions	1.47 g/h	1.94 g/h	3.1 g/h
Heating surface area	1 400 ft2	1 650 ft2	2 100 ft2
Combustion chamber	1.6 ft3	2 ft3	2.2 ft3
Weight	180 lb	205 lb	228 lb

16-Z (zero clearance)

Model	16-58 Z	16-68 Z	16-78 Z
EPA power	27 015 BTU\h	24 818 BTU\h	28 765 BTU\h
Maximum power	65 000 BTU\h	82 000 BTU\h	86 000 BTU\h
Nominal heat output	46 000 BTU\h	50 000 BTU\h	58 000 BTU\h
Efficiency	70.3%	61.6%	66.6%
Fine particle emissions	1.47 g/h	1.94 g/h	3.1 g/h
Heating surface area	1 400 ft2	1 650 ft2	2 100 ft2
Combustion chamber	1.6 ft3	2 ft3	2.2 ft3
Weight	232 lb	261 lb	288 lb

16-combo (firewood storage)

Model	16-58 Combo	16-68 Combo	16-78 Combo
EPA power	27 015 BTU\h	24 818 BTU\h	28 765 BTU\h
Maximum power	65 000 BTU\h	82 000 BTU\h	86 000 BTU\h
Nominal heat output	46 000 BTU\h	50 000 BTU\h	58 000 BTU\h
Efficiency	70.3%	61.6%	66.6%
Fine particle emissions	1.47 g/h	1.94 g/h	3.1 g/h
Heating surface area	1 400 ft2	1 650 ft2	2 100 ft2
Combustion chamber	1.6 ft3	2 ft3	2.2 ft3
Weight	378 lb	417 lb	452 lb
